What Size Electric Radiator Do I Need? Room Size and BTU Calculator

John Phelan

Shopping for electric radiators and heaters? See the range, with free delivery anywhere in Ireland from the first euro.

A white wall mounted electric radiator heating a bright living room, used to illustrate how to size a radiator to a room

Sizing an electric radiator correctly matters twice over. Undersize it and it runs flat out all evening without ever satisfying its thermostat, which is the most expensive way to run any heater. Oversize it and you paid for capacity you never use. The good news is that sizing is simple arithmetic, and this guide gives you the numbers for typical Irish rooms.

Radiator size and BTU calculator

Enter the room's length and width in metres, the ceiling height and how well the room holds heat.

12 m²floor area
1,200Wheat needed
4,094BTU per hour

One 1200W radiator suits this room.

See the 1200W Titan

Uses 100 watts per square metre for an average room, 125 for an older poorly insulated house and 85 for a well insulated new build, scaled up for ceilings over 2.4 metres. Rooms with big windows or more than one outside wall: go up a size. Then see what that size costs to run.

How do I work out what size electric radiator I need?

Allow roughly 100 watts per square metre of floor area. Measure the room's length by width in metres, multiply the two, then multiply by 100 for the wattage. The calculator above does it for you.

A slim white panel heater wall mounted low in a small bright Irish home office, showing the size of the heater against the room
A small home office of around 8 square metres is comfortably served by a single slim panel heater of 750W to 1000W.

A 3m by 4m bedroom is 12 square metres, so it needs around 1200W. That rule assumes a reasonably insulated room with a standard ceiling height of about 2.4 metres. For rooms in older houses, rooms with large windows, or rooms with more than one outside wall, go up a size rather than down. Heat rises, so rooms with high ceilings also need more than their floor area suggests.

Electric radiator size chart for Irish rooms

Room Typical size Radiator wattage
Box room or small office 6 to 8 m2 600W
Single bedroom 8 to 10 m2 900W
Double bedroom or home office 10 to 13 m2 1200W
Large bedroom or small sitting room 13 to 16 m2 1500W
Living room 16 to 20 m2 1800W to 2000W
Open plan living space Over 20 m2 Two radiators, sized per zone

These bands line up with the five sizes in the Titan Smart WiFi Electric Radiator range, which runs from a 600W four fin model up to an 1800W nine fin model.

How do I convert watts to BTU?

Multiply the watts by 3.412 to get BTU per hour, or divide BTU by 3.412 to get watts. A 1200W electric radiator gives out about 4,094 BTU an hour at full output.

Electric radiators are sold by wattage, so if a BTU calculator or an old heating spec gives you a BTU figure, convert it to watts and pick the next size up.

Radiator BTU per hour
600W 2,047 BTU
900W 3,071 BTU
1200W 4,094 BTU
1500W 5,118 BTU
1800W 6,142 BTU
2000W 6,824 BTU

Watts and BTU converter

How many BTU do I need for my room?

Allow about 341 BTU per hour for each square metre of floor in a reasonably insulated room with a 2.4 metre ceiling, which is the same as 100 watts. A 3m by 4m bedroom needs about 4,094 BTU, or 1200W. Older, poorly insulated rooms need around 427 BTU per square metre.

Is it better to go bigger or smaller if I am between sizes?

Go bigger. A slightly oversized radiator reaches temperature quickly and settles into economical cycling. An undersized one runs continuously and still leaves the room cold.

This feels backwards to many buyers, because the bigger radiator has a higher maximum draw. But the wattage rating is what the element draws while heating, not what it uses all evening. A 1500W radiator that holds a room at temperature while cycling on for twenty minutes in the hour costs less to run than a 900W unit drawing continuously and never getting there.

Do insulation and glazing change the answer?

Yes. Poor insulation, single glazing, high ceilings and more than one outside wall each push the requirement up. New well insulated builds can size down slightly.

For a room in an older uninsulated house, work off 120 to 130 watts per square metre rather than 100. If the room never held heat well with the old heating, that is the signal to size up. Conversely, a well sealed new build or a small room over a heated space can manage on 80 to 90 watts per square metre.

What about heating an open plan space?

Split the load across two radiators at opposite ends of the space rather than one very large unit in the middle.

A 30 square metre kitchen living space needs about 3000W of capacity, and two 1500W radiators heat it far more evenly than one 2000W unit working beyond its coverage. Two radiators on WiFi control can also run as one zone from the same app schedule.

Where can I get sizing advice before I buy?

Call Shamrock Electrical on 01 401 9907 with your room measurements and we will size it with you before you order, or send us your house plans and we will size and price every room for you. We are based in Rathcoole, Co. Dublin, just off the N7.

Browse the full range in electric radiators and heaters, including wall mounted electric heaters, with free delivery to every county in the Republic of Ireland and no minimum spend. For which type to choose once you know the size, see our guide to the most efficient electric heaters and radiators.

Can you price electric radiators from my house plans?

Yes. Send us a photo or PDF of your house plans and we will work out the right electric radiator for every room. It is not an automatic quote: one of our team looks at your plans and comes back to you with a price within 1 to 2 working days.

Builders, homeowners, landlords and property managers all use it, and you do not need to be an electrician. If you are pricing a whole house, a rental or a block of apartments, we size and price the lot in one go, and the quantity changes the price.

Send your plans on WhatsApp Email your plans

What to send with your plans

  • Plans that show the room sizes, or with the measurements written on. Architect drawings are ideal, and a clear phone photo is fine.
  • Which rooms you want to heat.
  • Whether it is a new build or an older house, and the BER rating if you know it. Well insulated new builds need smaller radiators, so this keeps the price down.
  • Whether you are trade or a homeowner, with your name, phone number and county.

This is for electric radiators and heaters, not radiators that run off a boiler or heat pump. We only use your plans to price your radiators.

Prefer to talk it through? Ring 01 401 9907, Monday to Friday 7am to 5pm and Saturday 9am to 1pm. Trade buyers can also see electric radiators at trade prices or request a trade quote.
